We regularly update our newsletter section with new and interesting items related to UV disinfection and water treatment in general.

Topics covered include new system announcements, consumer concerns, market opportunities and more.

If you have an idea that you would like to see covered in our newsletter section please contact us with details.


Pathogen Profile -
Escherichia coli

wild animals clipart

March 23, 2017

Escherichia coli commonly called E. coli refers to a group of bacteria that is typically found in the intestines of humans and animals.

It's important to know that many strains are harmless but some, such as E. coli 0157:H7 can make people and animals extremely ill and every year many thousands of people worlwide are sickened (or worse) by E. coli bacteria of this strain. The bacteria is named for it's founder, a German pediatrician.

There are many ways that humans can come into contact with E. coli and generally the risk is easily mitigated by using common sense hygiene and proper food cooking techniques. The risk of E. coli in drinking water is a real one and must be taken seriously especially by those using ground water or well water as their source of drinking water.

Food contamination typically occurs when beef and other meats are undercooked or when fruits and vegetables are not washed properly before consumption. E.coli contamination can pass easily from human to human and again this risk can be greatly mitigated by proper hand washing and other basic hygiene techniques.

E. coli in drinking water cannot be seen or easily otherwise detected. A home or lab test is typically used initially to detect coliform (an indicator bacteria for sanitary quality of water) which if detected usually means that other pathogens including E. coli are probably present. Diseases caused by pathogens which may possibly be present in water that tests positive for coliform may include cholera, typhoid fever, hepatitis, diarrhea, giardiasis and others.

The acceptable maximum count for E. coli in your drinking water is ZERO. If your water test indicates any coliform contamination then you must take immediate steps to solve to problem.

Common solutions for disinfecting drinking water are the application of chemical disinfectants such as chlorine and the application of UV light which is a non-chemical method to kill bacteria and viruses in water. Using UV light to kill all bacteria in the water supply is a highly effective and very cost-efficient method of protecting your drinking water on a 24/7 basis and it's easily accomplished without the risk of chemical overdose or the need to handle and store dangerous chemicals at home.

Wyckomar POU700 Systems



Wyckomar UV Purification Systems | 111 Malcolm Road | Guelph, ON, Canada N1K 1A8
Phone: (519) 822-1886 | Fax: (519) 763-6580 | sales@wyckomaruv.com | www.wyckomaruv.com

follow wyckomar on twitter   follow wyckomar on facebook



header

Pathogen Profile -
Leptospira interrogans

wild animals clipart

March 9, 2017

Most of us in the UV industry spend a lot of our time talking with customers about the common contaminants found in raw drinking water ... mostly this involves discussions about E.coli and Coliform as these are the two most common indicators of unsafe drinking water.

In this newsletter we are drawing attention to a less common pathogen but one that is found in many tropical and subtropical regions - and occasionally in more temperate climates too. The bacteria under discussion today is called Leptospira interrogans.

This bacteria is the cause of the zoonotic disease known as leptospirosis which as noted is more common in tropical and subtropical regions. Typically the bacteria is spread by animals that excrete the bacteria in urine and contaminate the surrounding soil and ground waters. This bacteria prefers warm and moist climates and can survive in the environment for months or even years. Contaminated water is the most common vector for human infection.

At risk populations include trappers, hunters and people living in rural areas including farmers and others. Outdoor activities including swimming and fishing may also increase the risk of contacting contaminated soil or water. Non-vaccinated pets may also carry the disease to human populations.

Consider that many homeowners, particularly in tropical and subtropical regions, often use a cistern for water storage. The cistern becomes the point of contamination when animals gain access to the cistern and excrete the bacteria into the water supply. This highlights the need for secure covers and access panels on all cisterns and water tanks of any type.

The UV Dose required to kill and inactivate Leptospira interrogans is very simple to achieve with a Wyckomar UV Disinfection system. A UV Dose of 6 mJ/cm2 will provide a 99.9% (3 log) kill rate and any model of Wyckomar UV disinfection system will provide much more UV than required for this target bacteria.

It's important to note that besides consuming the contaminated water, infection with this bacterium can happen with simple contact of contaminated water (through cuts on the skin etc). It's therefore recommended to install a whole-house UV disinfection system to ensure all water in the home is safe including drinking water plus bathing (showering) and laundry (utility) water.

The Wyckomar Sales Team



Wyckomar UV Purification Systems | 111 Malcolm Road | Guelph, ON, Canada N1K 1A8
Phone: (519) 822-1886 | Fax: (519) 763-6580 | sales@wyckomaruv.com | www.wyckomaruv.com

follow wyckomar on twitter   follow wyckomar on facebook

header
featured product

UV-5007 High-Volume
Extreme UV-Dose
Water Disinfection System
by Wyckomar


February 9, 2017


The UV-5007 system offers commercial applications and industrial users the opportunity to disinfect process water at high volumes and/or extreme UV-Doses for a wide variety of applications without using any chemical disinfectants whatsoever.

The UV-5007 System is a compact and efficient use of floor space, and can be modified and customized to suit your specific requirements. The system is designed in a modular fashion to allow additional modules to be easily attached for greater flow rates and/or greater UV-Dose requirements.

Wyckomar has been building UV disinfection systems since 1978, with installations around the world representing an impressive array of industry types and application requirements including food manufacturing and processing, beverage manufacturing and packaging, alcohol manufacturing and bottling, pool and pond disinfection and many more.

The large volume capability of the UV-5007 means that your process water is protected from all manner of disease-causing pathogens including bacterial, viral and cysts, instantly, and in real-time without the need for bulky and expensive holding tanks and chemical disinfectants. A single UV-5007 unit can provide an industry-standard UV-Dose of 40mJ/cm2 at a flow rate of more than 1400 LPM (370 GPM or 84 m3/hr) assuming 95% T water quality.

Some manufacturers require extreme UV-Dose applications for compliance, regulatory or other reasons and the UV-5007 is the right choice for these applications as well, providing up to 200 mJ/cm2 at flow rates of 300 LPM (80 GPM or 18 m3/hr assuming 95% T water). Of course the system may be configured any way you need, and any UV-Dose is possible to match your requirements.

UV Dose calculations are based on several factors including water quality and flow rate and every installation is unique. Contact us for specific UV Dose data for your disinfection requirements.

The Wyckomar Sales Team

Wyckomar UV-5007 Systems

Summary of Markets for the UV-5007 - Use it in almost any disinfection application including:

  • Food Manufacturing Processing and Packaging
  • Beverage Manufacturing and Bottling
  • Ice Making
  • Pharma Applications
  • Pools and Ponds
  • Domestic Water in Commercial Applications
  • Schools and Hospitals
  • Parks and Camps
  • Pre-Treatment for RO Water Facilities
  • Hotels and Laundries
      Ultraviolet light kills microorganisms

space


Wyckomar UV Purification Systems | 111 Malcolm Road | Guelph, ON, Canada N1K 1A8
Phone: (519) 822-1886 | Fax: (519) 763-6580 | sales@wyckomaruv.com | www.wyckomaruv.com

follow wyckomar on twitter   follow wyckomar on facebook

header
placeholder headline placeholder

January 27, 2017

The turning of a new year is a great time to review some (often neglected) market opportunities for UV water treatment systems.

Remember that UV disinfection technology is an ideal component of almost any type of water treatment system including RO and custom filtration systems.

UV ticks all the appropriate boxes:

inletgraphic1
UV is Green technology
inletgraphic3
UV is simple, proven technology
inletgraphic5
UV is extremely cost efficient when compared to chemical disinfection methods
inletgraphic7
UV can be applied in almost any water treatment application
inletgraphic9
UV offers you a chance to educate your customer and develop excellent customer relations
inletgraphic11


At Wyckomar, we are very pleased to be offering two updated systems designed to capture market opportunities across a wide scope of the water treatment industry - with a little thought and planning, these systems can be integrated into lots of different applications, and they may even bring about new (as yet unknown) markets by themselves.

Wyckomar Solar Tote

The Solar-Tote from Wyckomar is the portable water treatment solution for remote and off-the-grid applications including emergency preparedness. How many people do you know who are interested in preparing themselves for some measure of self-sufficiency?

The great thing about the Solar-Tote is that it is more than just a solar-powered water treatment system, it's also a complete power centre offering the ability to operate a wide range of electrical devices without relying on the power grid.

Compact, extremely adaptable and rugged, the Solar-Tote offers unlimited scope to develop new market opportunities for your business.

Wyckomar Blackguard WTS

The BlackGuard WTS is our latest product offering and it is getting a lot of interest in specific markets such as those with heavy metals contamination in the drinking water supply. We have designed the BlackGuard WTS system to be quite versatile in that it will provide 2 stages of water treatment meaning that Stage 1 water can be used as general utility water and Stage 2 water can be used as drinking water. In this case Stage 2 water has additional processing for the removal of heavy metals etc.

Look to introduce the BlackGuard WTS in markets with specific water treatment requirements (such as heavy metals contamination). This market can be surprisingly large and may include municipalities, trailer parks, commercial outlets using well water, houseboats and other watercraft plus many others.

Uniquely efficient, the BlackGuard WTS can offer an excellent over-all water treatment system for many applications and will be specifically well-received in regions with heavy metals and other dissolved contaminants in the water supply.

The Wyckomar Sales Team
